KAWA.Z AMP; KZ 900-1000 CC CHAIN AMP; SHAFT DRIV

MODELS COVERED:

Z1 (1973-1974)
KZ900 (1975-1976)
KZ1000 (1977-1978)
KZ1000 Standard (1979-1980)
KZ1000 Classic (1980)
KZ1000 Limited (1977-1980)
Z1R (1978-1980)
KZ1000 C Series Police (1978-1981)

This vintage Kawasaki motorcycle manual is 384 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Safety first / Expendable supplies / Shop tools / Emergency tool kit /Troubleshooting and tune-up equipment / Specifications

CHAPTER TWO / TROUBLESHOOTING
Starting difficulties / Poor performance / Clutch and transmission / Drive train / Chassis / Electrical system / Charging system / Lighting / Fuses / Wiring

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Scheduled maintenance / Weekly maintenance / Drive chain adjustment / Throttle adjustment/ Chain oil pump adjustment / Monthly maintenance / Six month maintenance / Tune-up / Air cleaner / Fuel system cleaning / Spark plugs / Cam chain adjustment / Air suction valves / Valve clearance / Contact points / Ignition timing / Throttle cable adjustment / Carburetors / Cylinder compression / Lubrication / Engine oil and filter / Chassis maintenance / Specifications

CHAPTER FOUR / ENGINE
Engine design / Break-in / Cam chain and tensioner / Camshafts / Valves / Cylinder block and pistons / Engine removal/installation / Oil pump / Crankcase / Crankshaft and cam chain / Specifications

CHAPTER FIVE / CLUTCH
Operation / Cable replacement / Release / Plates and hub / Specifications

CHAPTER SIX / TRANSMISSION
Transmission outer parts / Drive sprocket cover / Chain oil pump / Drive sprocket / Shift linkage / Front bevel drive / Transmission internal parts / Shift drum and forks / Input shaft / Output shaft / Kickstarter / Specifications

CHAPTER SEVEN / FUEL AND EXHAUST SYSTEMS
Fuel tank / fuel tap / Carburetors / Carburetor adjustment / Carburetor service / Accelerator pump / Air suction system / Crankcase breather / Exhaust system / Specifications

CHAPTER EIGHT / BRAKES
Brake fluid bleeding / Brake fluid change / Front brake pads / Front brake caliper / Rear brake pads / Rear brake caliper / Brake discs / Master cylinders / Rear drum brake / Specifications

CHAPTER NINE / WHEELS AND TIRES
Front wheel / Rear wheel / Wheel inspection / Tire changing / Inner tube repair / Tubeless tires / Specifications

CHAPTER TEN / CHASSIS
Front fork / Steering play / Steering head / Rear shock absorbers / Swing arm / Drive chain / Rear bevel drive / Drive shaft / Specifications

CHAPTER ELEVEN / ELECRICAL SYSTEM
Fuses / Battery / Charging system / Charging system test / Alternator / Ignition system / Spark plugs / Ignition advance / Condenser / Ignition coil / Pickup coils / IC igniter / Starting system / Starter clutch / Starter solenoid / Lighting system / Fuel gauge / Z1R circuits / Horn / Specifications

SUPPLEMENT / 1980-1981 SERVICE INFORMATION

INDEX

WIRING DIAGRAMS
