HONDA VT1100 SERIES 1995-2007

MODELS COVERED:

VT1100C Shadow Spirit (1997-2007)
VT1100C2 Shadow 1100 American Classic Edition (1995-1999)*
VT1100C2 Shadow Sabre (2000-2007)
VT1100C3 Shadow Aero (1998-2002)
VT1100T Shadow 1100 American Classic Edition Tourer (1998-2000)

* Except for color and decal changes, the VT1100C2-2 and the VT1100D2 models are the same motorcycle as the VT1100C2 Shadow 1100 American Classic Edition.

This Honda Motorcycle Manual is 568 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Basic tools / Precision measuring tools / Electrical system fundamentals / Basic service methods / Storage / Specifications

CHAPTER TWO / TROUBLESHOOTING
Engine principles and operating requirements / Starting the engine / Engine will not start / Poor engine performance / Fuel system / Engine / Engine lubrication / Hydraulic tappets / Cylinder leak down test / Clutch/ Gearshift linkage / Transmission / Final drive / Electrical testing / Front suspension and steering / Brakes

CHAPTER THREE / PERIODIC LUBRICATION, MAINTENANCE AND TUNE-UP
Routine checks / Maintenance intervals / Periodic lubrication / Oil and filter change / Periodic maintenance / Tune-up / Ignition timing / Specifications

CHAPTER FOUR and FIVE / ENGINE
Cylinder head covers and rocker arms / Hydraulic tappets / Camshafts / Cam chain tensioner / Cylinder head / Valves and components / Cylinder / Piston and rings / Oil jet / Removal / installation / Crankcase and crankshaft / Crankcase bearing / Crankshaft / Connecting rods / Output gear / Output gearcase overhaul / Engine break-in / Specifications

CHAPTER SIX / CLUTCH, PRIMARY DRIVE GEAR, GEARSHIFT LINKAGE AND OIL PUMP
Clutch release lever / Right crankcase cover / Oil pump chain and sprockets / Primary drive gear / External shift mechanism / Oil pump / Specifications

CHAPTER SEVEN / TRANSMISSION AND INTERNAL SHIFT MECHANISM
Mainshaft / Countershaft / Internal shift mechanism / Specifications

CHAPTER EIGHT / FUEL AND EMISSION CONTROL SYSTEMS
Carburetor operation service adjustment / Fuel filter / Air filter housing and fuel pump / Fuel tank / Crankcase breather system / Evaporative emission control system / Pulse secondary air injection PAIR system / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Charging system / Left crankcase cover and stator coil / Flywheel, starter clutch, starter reduction gears and gearshift spindle A / Ignition system troubleshooting / Ignition coils / Ignition pulse generator / Ignition control module ICM / Starter drive gear and torque limiter / Starter / Headlight / Speedometer and speed sensor / Coolant temperature switch / Coolant temperature indicator check unit / Fan motor switch / Oil pressure indicator and oil pressure switch / Sidestand switch / Clutch switch / Front brake light switch / Rear brake light switch / Ignition switch / Handlebar switch / Turn signal relay / Diodes / Horn / Fuses / Specifications

CHAPTER TEN / COOLING SYSTEM
Temperature warning system / Inspection / Hoses / Pressure test / Radiator / Cooling fan / Coolant reserve tank / Thermostat / Coolant temperature switch / Water pump mechanical seal inspection / Water pump / Specification

CHAPTER ELEVEN / WHEELS AND TIRES
Final driven flange / Front and rear hubs / Wheel service / Specifications

CHAPTER TWELVE / FRONT SUSPENSION AND STEERING
Handlebar / Front fork / Steering head and stem / Steering bearing preload / Steering head and stem bearing race / Specifications

CHAPTER THIRTEEN / REAR SUSPENSION AND FINAL DRIVE
Shock absorber / Swing arm / Final drive unit and drive shaft / Final drive unit / Specifications

CHAPTER FOURTEEN / BRAKES
Brake pads / Caliper / Master cylinder / Rear master cylinder reservoir / Brake disc / Brake bleeding / Drum brake / Brake pedal / Specifications

CHAPTER FIFTEEN / BODY AND EXHAUST SYSTEM
Seat / Side covers / Steering covers / Windshield / Saddlebags / Fenders / Footrest / Left crankcase rear cover / Exhaust system / Specifications

INDEX

COLOR WIRING DIAGRAMS
