KAWASAKI KZ ZX AMP; ZN 1000-1100CC 81-02

MODELS COVERED:

U.S. and Canada Models
KZ1000 J1, J2 (1981-1982)
KZ1000 K1, K2 LTD (1981-1982)
KZ1000 M1, M2 CSR (1981-1982)
KZ1000 R1, R2 Replica (1982-1983)
KZ1100 A1, A2, A3 Standard (1981-1983)
KZ1100 B1, B2 GP (1981-1982)
KZ1100 D1, D2 Spectre (1982-1983)
KZ1100 L1 LTD Shaft Drive (1983)
ZX1100 A1, A2 (1983-1984)
ZN1100 B1, B2 (1984-1985)
Z10000 Police Model P1-P21 (1982-2002)

This Kawasaki motorcycle manual is 376 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Safety first / Expendable supplies / Shop tools / Emergency tool kit / Troubleshooting and tune-up equipment / Specifications

CHAPTER TWO / TROUBLESHOOTING
Starting difficulties / Poor performance / Clutch and transmission / Drive train / Chassis / Brakes / Electrical system / Charging system / Lighting / Fuses / Wiring / Specifications

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Model identification / Scheduled maintenance / Engine oil and filter / Drive chain lubrication / Swing arm lubrication / Steering head lubrication / Wheel bearing lubrication / Shaft drive lubrication / General lubrication / Battery / Air filter / Clutch adjustment / Drive chain adjustment / Steering play inspection / Front forks / Rear shock absorbers (dual shock models) / Rear shock absorbers (uni-track models / Tires / Wire wheels / Cast wheels / Disc brake / Nuts, bolts and fasteners / Engine tune-up / Fuel system / Spark plugs / Air suction valves / Valve clearance / Ignition timing / Carburation or fuel injection / Cylinder compression / Storage / Specifications

CHAPTER FOUR / ENGINE
Break-in / Cam chain and tensioner / Valve cover / Camshafts / Cylinder head / Valves and valve components / Cylinder block / Pistons and rings / Oil cooler / removal installation / Oil pump / Crankcase / Crankshaft and cam chain / Crankcase assembly / Specifications

CHAPTER FIVE / CLUTCH
Operation / Clutch release / Overhaul / Specifications

CHAPTER SIX / TRANSMISSION
Sprocket cover / Engine sprocket / Neutral switch / Shift linkage / Shift drum and forks / Transmission gears / Front bevel drive / Specifications

CHAPTER SEVEN / CARBURETION AND EXHAUST SYSTEMS
Carburetor operation service troubleshooting / Rejetting / Fuel level inspection / Idle mixture adjustment / Crankcase breather / Air suction system / Fuel tank / Fuel tap / Fuel level sending unit / Exhaust system / Specifications

CHAPTER EIGHT / FUEL INJECTION SYSTEM
Fuel injection operation / Fuel injection precautions / Fuel injection scheduled maintenance / Fuel injection testing / Quick diagnosis / Fuel system tests / Control unit system tests / Sensor tests / Signal test / Last chance / Fuel injection disassembly / Control unit / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Fuses / Battery / Ignition system / Spark plugs / Ignition coils / Pickup coils / Ignition advance mechanism / IC igniter / Charging system / Alternator / Starting system / Starter motor / Starter clutch / Starter solenoid / Starter lockout switch / Lighting system / Turn signal cancelling system / Fuel gauge / Fuel level sensor / Electric instruments / Tachometer/voltmeter / Electronic warning unit / Horn / Voltmeter / Specifications

CHAPTER TEN / WHEELS, TIRES AND BRAKES
Wire wheels / Cast wheels / Front rear wheel / Wheel bearings and seals / Axle / Brakes / Brake system bleeding / Brake fluid change / Brake hose / Brake pads and calipers / Front rear master cylinder / Brake discs / Specifications

CHAPTER ELEVEN / CHASSIS
Fairing / Handlebars / Front forks / Steering / Shock absorbers / Swing arm / Uni-track rear suspension / Drive chain / Final gear case / Swing arm / Drive shaft / Specifications

SUPPLEMENT / 1982-2002 POLICE MODEL SERVICE INFORMATION

INDEX

WIRING DIAGRAMS
