YAM DT AMP; MX SERIES SNGLS 77-83

MODELS COVERED:

DT100 (1977-1983)
DT125 (1978-1981)
DT175 (1978-1981)
DT250 (1977-1979)
DT400 (1977-1978)
MX100 (1979-1983)
MX175 (1979-1981)

This Yamaha Vintage Classic Motorcycle Manual is 320 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Torque specifications / Safety First / Special tips / Parts replacement / Expendable supplies / What year is it? / Serial numbers / Basic hand tools / Tune-up and troubleshooting tools / Fasteners / Mechanic's tips / Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Emergency troubleshooting / Engine starting / Engine performance / Engine noises / Excessive vibration / Two-stroke pressure test / Front suspension and steering / Brake problems

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Routine checks / Pre-checks / Tires and wheels / Battery / Periodic lubrication / Checking engine oil / Transmission oil checking and changing / Front fork oil change / Drive chain lubrication / Periodic maintenance / Monoshock adjustment / Drive chain adjustment / Clutch adjustment / Autolube oil pump adjustment / Throttle adjustment / Air cleaner / Pulsating Air System (air injection) - DT250F only / Engine tune-up / Cylinder head nut torque / Spark plug / Ignition timing (CDI - capacitor discharge ignition) / Ignition timing (breaker point ignition) / Idle speed adjustment / Exhaust decarbonizing / Storage / Specifications

CHAPTER FOUR / ENGINE
Engine principles / Engine lubrication / Engine cooling / Servicing engine in frame / Cylinder head / Cylinder / Piston, piston pin and piston rings / Break-in procedure / Magneto / Oil pump / Reed valve assembly / Compression release (DT 400D only) / Crankcase and crankshaft / Kickstarter / Service and adjustment / Specifications

CHAPTER FIVE / CLUTCH AND TRANSMISSION
Clutch / Clutch cable / Clutch release (push lever) mechanism / External shift mechanism / Transmission and internal shift mechanism / Specifications

CHAPTER SIX / FUEL AND EXHAUST SYSTEMS
Air cleaner / Carburetor service / Carburetor operation / Carburetor adjustments / Fuel shutoff valve / Fuel tank / Fuel filter / Exhaust system / Exhaust system decarbonizing / Exhaust system repair / Specifications

CHAPTER SEVEN / ELECTRICAL SYSTEM
Charging system (DT series only) / Battery / Magneto / Voltage regulator (DT series only) / Rectifier (DT series only) / Contact breaker point ignition / Capacitor discharge ignition / Spark plug / Ignition coil / Lighting system (DT series only) / Switches / Electrical components / Wiring diagrams / Specifications

CHAPTER EIGHT / FRONT SUSPENSION AND STEERING
Front wheel / Front hub / Wheels / Tire changing / Tire repairs / Handlebar / Steering head / Front fork / Specifications

CHAPTER NINE / REAR SUSPENSION
Rear wheel / Rear hub / Drive sprocket (all models except DT100 and MX100) / Drive sprocket assembly (Model DT100 and MX100) / Drive chain / Wheel balancing / Tire changing and tire repairs / Rear swing arm / Monoshock rear suspension (Decarbon Monocross system) / Dual-shock rear suspension (DT100 and MX100) / Specifications

CHAPTER TEN / BRAKES
Front brake / Rear brake / Rear brake pedal assembly / Specifications

CHAPTER ELEVEN / FRAME AND REPAINTING
Kickstand (sidestand) / Footpegs / Frame / Specifications

INDEX

WIRING DIAGRAMS
