Stock # 252M335

HON CX AMP; GL500/650 TWINS 78-83

In Stock

Dealer Price $63.99 CAD

Add to Cart

Get a Quote Get Financed Value a Trade Contact Us Book a Demo Get Directions Get Directions Print

Overview

MODELS COVERED:

CX500 (1978)
CX500 Custom (1979-1982)
CX500 Deluxe (1979-1982)
CX650C (1983)
GL500 (1981-1982)
GL500 Interstate (1981-1982)
GL650 (1983)
GL650 Interstate (1983)

This Honda motorcycle manual is 320 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Safety first / Parts replacement / Expendable supplies / Tools / Serial numbers / General specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Emergency troubleshooting / Engine / Charging system / Starter / Engine noises / Excessive vibration / Lubrication troubles / Fuel system / Clutch / Transmission / Brakes / Lighting system / Front suspension and steering

CHAPTER THREE / PERIODIC MAINTENANCE AND LUBRICATION
Routine / Service intervals / Tires / Battery / Periodic lubrication / Periodic maintenance / Tune-up

CHAPTER FOUR / ENGINE
Engine principles / Servicing engine in frame / Engine removal and installation / Cylinder head / Valve and valve seats / Upper rocker arm assemblies / Camshaft / Camshaft chain and tensioner / Lower rocker arm assemblies / Piston and connecting rods / Alternator / Oil pump / Oil pressure relief valve / Cylinder block/crankcase / Crankshaft / Starter gears and clutch / Break-in / Specifications

CHAPTER FIVE / CLUTCH AND TRANSMISSION
Clutch / Clutch cable / Shifting mechanism / Transmission / Gearshift drum and forks / Final shaft

CHAPTER SIX / FUEL AND EXHAUST SYSTEMS
Air cleaner / Carburetors / Fuel shutoff valve / Fuel tank / Crankcase breather system / Exhaust system

CHAPTER SEVEN / ELECTRICAL SYSTEM
Charging system / Battery / Alternator / Voltage regulator/rectifier / Ignition system / Ignition coil / Capacitor discharge system / Spark plugs / Starting system / Starter / Lighting / Fuses

CHAPTER EIGHT / COOLING SYSTEM
Checks / Radiator / Fan / Thermostat / Coolant change / Water pump

CHAPTER NINE / FRONT SUSPENSION AND STEERING
Front wheel / Front hub / Wheel balancing / Tire changing / Handlebar / Steering head / Front fork

CHAPTER TEN / REAR SUSPENSION AND FINAL DRIVE
Rear wheel / Rear hub / Tire change / Final drive / Drive shaft/rear swing arm / Rear shocks

CHAPTER ELEVEN / BRAKES
Front disc brake / Rear drum brake

CHAPTER TWELVE / FRAME

SUPPLEMENT / 1980 AND LATER SERVICE INFORMATION

INDEX

COLOR WIRING DIAGRAMS
